The Mackie 802VLZ4 is, first and foremost, a Mackie mixer. It houses three of Mackie's premium-quality Onyx mic preamps for natural, transparent sound, and three stereo channels. Its mic/line channels are equipped with a 3-band EQ. Signal routing is easy and flexible. On top of all that, the Mackie 802VLZ4 is built Mackie-tough - trust this mixer to perform even in the most harrowing situations.
Sure, the Mackie 802VLZ4 mixer will shrug off bumps, drops, and outright abuse, but what about spills or rain? Thankfully, the 802VLZ4 boasts sealed rotary controls that resist grime, dust, and anything else that may spill onto your mixer. We're not saying it's fully waterproof, but it's an extra level of protection you'll eventually be very glad you have when you're running live sound in a hectic environment.
VLZ stands for "very low noise", and that's just part of the appeal of the Mackie 802VLZ4 mixer. In all you've got a 128.5dB dynamic range, making it easy to achieve full, punchy mixes. The Onyx mic preamps have a 60dB gain range, so you can get the best out of virtually any microphone. And because the 802VLZ4's line inputs handle +22 dBu signal levels, you can connect high-output sound sources without worrying about distorting your inputs.
Mackie relentlessly pursues the perfection of the compact mixer. VLZ4 ups the level of sonic quality at every level, featuring Mackie's flagship Onyx mic preamps and premium components from front to back. The result is the most rock solid, the most easy to use and, yes, the best sounding compact mixer ever created.
Type |
Analog Mixer with Onyx Preamplifiers |
---|---|
Channels | 8 |
Inputs - Mic Preamps | 3 x XLR (CH 1-3) |
Phantom Power | 3 |
Inputs - Line |
2 x 1/4" (CH 1-2), 6 x 1/4" (CH 3-8 Stereo) |
Inputs - Other | 2 x Stereo (RCA) |
Outputs - Main | 2 x XLR, 2 x 1/4" |
Outputs - Other |
2 x RCA (Tape), 2 x 1/4" (Alt), 2 x 1/4" (Control Room) |
Aux Sends | 1 x Pre/Post |
Send/Return I/O | 1 x 1/4" (Send), 2 x 1/4" (Return) |
Busses/Groups |
Alt 3-4 |
Channel Inserts |
Yes (CH 1-2) |
Headphones |
1 x 1/4" |
EQ Bands |
3-band |
Rackmountable | Yes |
Power Source |
12V DC power supply (included) |
Height | 1.8" |
Width |
8.9" |
Depth |
10.7" |
Weight | 5.5 lbs. |
Manufacturer Part Number |
2040767-00 VLZ4 |
